GNSS Solution

AP5168G

Multi-band GNSS module

Specification

Form factor Stamp type
Dimension 10x10mm
Band L1/E1, B1/B2a and L5/E5a
Certification FCC/CE pre-test
Spec 36 Channels
Support GPS/GLONASS/GALILEO/BEIDOU3/IRNSS
interface UART/SPI
Operating temperature -20 °C to 75 °C
Driver support Linux, Android, RTOS
Datasheet
EVB

Product Overview

The AMPAK Technology® AP5168G is a latest GNSS functionality module. The module simultaneously supports GNSS, GLONASS (GLO), BeiDou (BDS), Galileo (GAL), NAVIC, and QZSS in both the L1/B1/E1 and L5/E5a/B2a frequency bands. The GNSS core host-base in the modules splits processing functions between the GNSS device and the CPU on the host system. In addition, this module is a compact solution with low power consumption for GNSS technologies. The module is specifically developed for wearable devices and mobile accessories.




Capacity
Speed
Connection
Battery Life

For more information about our products please contact AMPAK sales.
